CAMEO LIGHTS PIXBAR DTW PRO

CAMEO LIGHTS PIXBAR DTW PRO

$0.00Price
12 x 10 W Tri-LED Bar with Variable White Light and Dim-to-Warm Control

Item No.: CLPIXBARDTWPRO

  • 12 x 10 watt Tri-LEDs 3-in-1 Cool White, Warm White and Amber

  • Full white temperature control from Tungsten to CW (1,600 - 6,800 K)

  • CRI 97 @ 2,800 K for natural colour rendering

  • Dim to Warm (DTW) technology to emulate halogen-style dimming

  • Single pixel control for stunning chase and pixel mapping effects

  • Selectable 16-bit dimming curves and response

  • RDM enabled

  • 9 DMX modes plus sound activation and automated operation

  • Highly efficient convection cooling for noiseless operation

  • Flicker free for use in TV and film applications

  • Glare shield and frost filter included

  • Omega bracket set available as accessory

  • Description

    Featuring twelve 10 watt 3-in-1 cool white, warm white and amber Tri-LEDs, the Cameo PIXBAR DTW PRO permits full white temperature control from warm Tungsten white to ultra bright cool white. The professional LED bar features an 18° beam angle and Dim-to-Warm technology to emulate the smooth dimming of halogen lamps. Highly efficient convection cooling and a 3,000 Hz refresh rate ensure absolutely noiseless and flicker-free operation making it a perfect choice for TV and film applications.



    The PIXBAR DTW PRO is RDM enabled and provides 9 modes of DMX control, sound activation plus automated operation. The fixture includes single pixel control for impressive chase effects and pixel mapping, a high-speed strobe and selectable 16-bit dimming curves with adjustable response. A 4-button display enables easy configuration. The rugged aluminium housing features 3 and 5-pin DMX and Neutrik powerCON inputs and outputs that enable convenient daisy chaining. The PIXBAR DTW PRO comes with a glare shield and frost filter if softer washes are called for.

  • Specification

    Product type LED Bars
    Type Washer
    Colour spectrum cold white , warm white , yellow
    Number of LEDs 12
    LED type 10 W (ca. 50000 operating hours)
    Refresh rate 3000 Hz
    Dispersion 18° Beam, 30° Beam Field (without Diffusor) °
    Lens PE
    DMX input XLR 3-pin male
    DMX output XLR 3-pin female
    DMX mode 1-channel , 13-channel , 2-channel , 3-channel , 36-channel , 49-Channel , 6-channel , 9-channel
    DMX Functions Auto Mode , Automode-Speed , Color Temperature , Dim LEDs seperate , Dim to Warm , Dimmer , Sound to Light , strobe
    Standalone modes Master / Slave mode , Static
    Controls Enter , Mode , Value Down , Value Up
    Indicators LC display
    Operating voltage Glare Shield , Neutrik Power Cable
    Power consumption 130 W
    Power connector Neutrik powerCON IN / OUT
    Housing material Aluminium
    Cabinet colour Black
    Protection class IP 20
    Cooling Convection Cooling
    Luminous flux 3240 lm
    Efficiency 25 lm/W
    Operating Temperature -15 - 45 °C

    Dimensions including Mounting Bracket

    Width 93 mm
    Height 130 mm
    Length 900 mm
    Weight 7,8 kg
    Accessories (included) FROST Filter , Glare Shield , Neutrik Power Cable
