LD SYSTEMS MAUI 11 G2 W
Portable Column PA System with Mixer and Bluetooth white
Item No.: LDMAUI11G2W
- All-in-one column speaker for PA and monitor applications
- 1,000 watts peak Class-D system power offer high performance with a low weight
- Powerful bass reproduction with 3 x 6.5" woofers
- Balanced mids thanks to the 8 x 3" full-range speakers
- Precise and silky highs with 2 x 1" high-frequency drivers
- Increased range and wider coverage through the array arrangement
- Homogeneous dispersion pattern through a BEM-optimised tweeter wave guide
- Distortion-free sound even at the highest volume thanks to LD Systems DynX® DSP technology
- Full control through a 4-channel mixer including Bluetooth® Stereo Audio Streaming
- Two-piece column for compact transport
- Secure plug-and-play connection thanks to the wireless multi-pin mechanism
- A wide range of application options through dismountable columns
- Easy operation with presets for mono or stereo configuration
- Extensive and smart accessories for installation and transport
Description
A complete sound system that you can carry together with your instrument: introducing the MAUI 11 G2. The two column elements in the padded shoulder bag, the subwoofer in one hand and the guitar or keyboard in the other - and off you go! Setting up the complete system, which doubles as a PA and monitor system is just as easy thanks to the special multi-pin cable plugs. The compact and elegant MAUI 11 G2 offers an unbeatable sound quality and wide-ranging sound distribution. It was developed after years of experience in the design of the column systems as a user-friendly solution for small to medium-sized gigs and fixed installations.
The MAUI 11 G2 is equipped with three 6.5" woofers, eight 3" full-range speakers and two 1" neodymium HF drivers. They are driven by a light Class-D power amplifier boasting 1,000 watts of peak power and producing a grunty bass, balanced mids and precise and silky highs. The DynX® DSP technology from LD Systems provides top-class performance each time and the highest level of freedom from distortion. It includes a multiband limiter which protects against overloading, an EQ, a compressor and a 3-way-crossover with run time correction.
The design of the MAUI 11 G2 line array achieves a longer range, increased resistance to feedback and a wider space coverage, which makes separate monitor speakers superfluous. The wave guide of the tweeters has been developed using the Boundary Element Method (BEM), a numerical simulation of the sound radiation and dispersion. It reduces reflections from the floor and ceiling and prevents sidelobe levels and thus achieves an homogeneous dispersion - Your audience hears you in the back row just as clearly as in the front.
With the integrated 4-channel mixer, system presets for mono or stereo configuration and Bluetooth® Audio Streaming, you have full control over the system. Whether you are a singer-songwriter, solo entertainer or DJ, you will be thrilled with the extraordinary sound and portability of the MAUI 11 G2. The column and the subwoofer can be set up separately: thus, the system is extremely flexible and is also an excellent choice for fixed installations. With a selection of clever transport accessories and special mounting hardware, the MAUI 11 G2 is a well thought out overall solution, down to the last details.
Specification
Product type PA Complete Systems Type active Colour white Max. SPL (peak) 124 dB Frequency response 50 - 20000 Hz Dispersion (H x V) 120° x 20 ° Overall height 2030 mm Weight 24,9 kg Woofer characteristics
Low/mid driver dimensions 3 x 6.5 " Woofer size 3 x 165.1 mm Woofer magnet Ferrite Woofer brand Custom-made Woofer voice coil 1.5 " Woofer voice coil (mm) 38.1 mm Cabinet construction vented Cabinet material 15 mm Plywood Cabinet surface texture paint Subwoofer width 285 mm Subwoofer height 650 mm Subwoofer depth 373 mm Subwoofer weight 16.9 kg Mid/Hi System
Midrange size 8 x 3 " Midrange size 8 x 76.2 mm Midrange magnet Ferrite Midrange brand Custom-made Midrange voice coil 1 " Midrange voice coil 25.4 mm Horn Waveguide Tweeter dimensions 2 x1 " Tweeter dimensions (mm) 25.4 mm Tweeter magnet Neodymium Tweeter brand Custom-made Tweeter voice coil 1 " Tweeter voice coil (mm) 25.4 mm Loudspeaker inputs 1 Speaker input connections Custom-made multipin Cabinet construction mid/high Closed Mid/Hi system cabinet material Aluminium Mid/Hi system cabinet surface HD coating Mid/Hi system width 96 mm Mid/Hi system height 620 / 730 mm Mid/Hi system depth 104 mm Mid/Hi system weight 5.4 / 2.6 kg Amplifier module (integrated in subwoofer)
Amplifier Class D Amplifier output system (RMS) 500 W Amplifier output system (peak) 1000 W Protection circuits DC protection , Multiband limiter , short circuit , thermal overload Cooling Convection Operating Temperature 0 - 40 °C Humidity Range 10% to 80%, (non-condensing) Controls Bluetooth switch , Hi-Z Level , Line level , Main level , Mono/stereo switch , MP3/Bluetooth Level , Power , Sub level Indicators Limit , mono , On , Protect (protection circuit engaged) , Setup , Signal , stereo Power connector IEC power cable (included) Operating voltage 100 - 120 V / 50 - 60 Hz or 200 - 240 V / 50 - 60 Hz (automatic switching) Power consumption Off / On / Max. 0/11/600 W Line inputs 2 x stereo Line input connectors RCA , XLR/6.3 mm jack Line outputs 1 x direct out Line output connectors XLR Mic inputs 1 Mic inputs XLR/6.3 mm jack MP3 inputs 1 MP3 input connectors 3.5 mm jack Hi-Z inputs 1 Hi-Z input connectors 6.3 mm jack Loudspeaker outputs 1 Speaker output connections Custom-made multipin DSP characteristics
Bit depth AD/DA converter 24 bit Internal sampling frequency 48 kHz Signal/noise ratio 100 dB
